stud roll forming machine

stud roll forming machine Production technology: Strip coil unloading----Cold bending forming----Hydraulic cutting-------Loading. Equipment configurations: 1. 1 set of double-disc rotating tension unloading machine. · Weight of the single-head coil is 1000Kg, internal hole of the coiling materials isΦ450600mm and external diameter of the coiling materials is 1200mm. 2. 1 set of forming host (12 channels) machine group. · Roller shaftΦ50mm, extended width 300mm and interval of the machine frame 420mm. · 1 set of guide frame at loading port and 1 set of straightness calibration device at unloading port. · Upper and lower universal shaft for transmission at the distribution box. 3. The main transmitter is 11KW frequency conversion timing, equipped with helix gear reducer. 4. 1 set of hydraulic tracking flying cutting machine. · 1 set of hydraulic station, motor 5.5KW, air-cooled and cutting rate 25 times/minute. 5. 1 set of pneumatic collection table of 4M long. · Pneumatic material overturning.
